Beijing Chuanglong Century Science & Technology Development Co., Ltd.
3 Years
| Ask Lasest Price | |
| Brand Name : | Shenzhou Anfu |
| Model Number : | AF75 |
| Certification : | ISO,Test Report |
| Price : | US$45-55/pc |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 20000-40000/Month |
| Delivery Time : | 2-15days |
Company Information
Beijing Shenzhou Anfu Company, commonly known as Shenzhou Anfu, stands at the forefront of high-tech enterprises specializing in security solutions. Our expertise spans across the design, development, and sales of security SOC chips, modules, and terminal products.
We take pride in our array of prestigious certifications, including:
At Shenzhou Anfu, our primary focus lies in pioneering basic research and development in the security domain. Leveraging a robust 32-bit embedded high-performance CPU SOC chip design platform, we have successfully developed a range of SOC chip products and applications tailored for information security and mobile payment. Our end-to-end solutions encompass design, production, sales, and service, fostering the industrialization of advanced security technologies.
Our products are integral to various fields, including:
Innovation is the backbone of Shenzhou Anfu. We have secured 14 independent intellectual property rights, encompassing:
Our relentless pursuit of innovation is evidenced by substantial annual investments in research and development. This dedication has resulted in the successful serial production of our AX200 chip products and the introduction of multiple industry-specific security solutions.
Through cutting-edge technology, strategic decision-making, and rigorous management standards, Shenzhou Anfu has evolved into a renowned leader in the field of security encryption. We proudly serve as a trusted supplier of independent security chips, modules, and intelligent security terminals, catering to diverse sectors such as security, banking and finance, e-government, and convenience services, both domestically and internationally.
Shenzhou Anfu’s commitment to excellence and innovation has positioned us as a pivotal player in the security industry, continually pushing the boundaries to deliver advanced, reliable security solutions for a safer world.
Specification
| Operating System | Linux 5.4 RTOS |
| Processor | Linux:Cortex-A7 1.2 GHz RTOS:Cortex-A5 500MHz High performance 32-bit security CPU |
| Memory | Linux:256MB Flash + 128MB RAM RTOS:8MB Flash + 16MB RAM |
| Card Readers | MSR: ISO7810-7813, 3 tracks IC Card: ISO7816 |
| NFC Reader | 13.56MHz, ISO/IEC14443 TypeA&B, |
| Camera | Rear camera:0.3 million pixels |
| Display | 2.8" 320x240 TFT Resistive Touch Screen |
| Wireless Communication | Linux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS) RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS) |
| Battery | emovable Lithium polymer battery, 3.7V/2500mAh | 3.7V/3200mAh (optional) |
| Printer | High speed thermal printing, printing lifeis not less than 50km The specification is 58mm in width and 40mm in diameter |
| Card Slots SIM / SAM | SIM Card x 2 + PSAM X 1 |
| Positioning | X |
| Keypad | Numeric x 10 Function x 8 Power x 1 |
| Audio | 1 Buzzer |
| Ports | Linux:1 Type-C USB OTG | USB 2.0 RTOS:11 Type-C | USB 2.0 |
| Indicator lights | 4 Work indicator lights |
| Adapter | Input: AC 100-240V, 50/60Hz Output: 5V/1A |
| Scanning charging base | X |
| Weight | 340g |
| Physical size | 177mm*81mm*56mm |
| Environment | Storage temperature: -20°C to 60°C Operating temperature: -10°C to 50°C Humidity: ≤95% |
| Certifications | EMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave
/Mastercard Paypass PCI PTS 6.x / TQM / CE |
| Display | 2.8"(320 x 240)TFT, resistive touch screen |
| WlFl(optional) | 802.11 a/b/g/n,2.4G |
| Mobile communication | Linux:4G CAT4,WCDMA,GSM RTOS:4G CAT1,GSM South American Version FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B; TDD-LTE:B40 GSM:B2/B3/B5/B8 European Version FDD-LTE:B1/B3/B5/B7/B8/B20; TDD-LTE:B38/B40/B41 GSM:B3/B8 |
| Contact lC card | Comply with lS0 7816 and China financial integrated circuit (lC) card specification; The card holder can be used for more than300000 times |
| Magnetic stripe card | Support three track data reading; It supports two-way card swiping. The swipingspeed ranges from 10 cm /s to 100 cm /s. The service life of the magnetic stripe reader canreach more than 400000 times; It conforms to iso78ll and iso7812 standards |
| RTC | Built in RTC to save the clock; Buttonbattery life > 5 years |
| Products Name | MOQ(in the last 12month) |
| POS Device | 5 Pieces |
Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.
Certificate
FAQ
1. Q: How can I get the touch pos terminal sample to check quality?
After price comfirmation, you can order pos samples to check quality.
Contact:whatsapp +86 18011965815
2. Q. How can we promise you the quality ?
Each of our products will be FULL tested and Inspected before it
shipped,
3. Q: How can I become your agent?
A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.
4. Q: Who will pay the postage of the returns?
A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)
5. Q:What is your warranty?
We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
|
|
