Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75

Beijing Shenzhou Anfu Technology Co. Limited
Contact Now
    Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers

    Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers
    • Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers
    • Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers
    • Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers
    • Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers
    • Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers
    • Buy cheap Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75 from wholesalers

    Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75

    Ask Lasest Price
    Brand Name : Shenzhou Anfu
    Model Number : AF75
    Certification : ISO,Test Report
    Price : US$45-55/pc
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 20000-40000/Month
    Delivery Time : 2-15days
    • Product Details
    • Company Profile

    Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75

    Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine with Printer 1D/2D QR Scanner AF75


    Company Information


    Beijing Shenzhou Anfu Company (Shenzhou Anfu) is a high-tech enterprise specializing in the design, development, and sales of security SOC (System on Chip) chips and modules, as well as security terminal products. It has established a significant presence in the security technology sector, backed by several important certifications:

    • National High-Tech Enterprise Certification
    • UnionPay Card Acceptance Terminal Product Enterprise Certification
    • Software Enterprise Certification
    • ISO 9001:2015 Quality Management System Certification
    • Designated Production Unit and Sales License for Commercial Password Products by the State Password Administration

    Core Competencies and Product Focus

    Shenzhou Anfu is dedicated to basic research and development in security technologies. The company's key areas of expertise include:

    • 32-bit Embedded High-Performance CPU SOC Chip Design: Leveraging advanced platforms for developing high-performance embedded CPUs.
    • Information Security and Mobile Payment Solutions: Designing SOC chips tailored for secure information handling and mobile payment systems.
    • Industrialization and Product Application: Promoting products across various sectors such as intelligent terminals, security products, smart homes, smart locks, financial payments, and specialized information encryption products.

    Intellectual Property and Innovation

    Shenzhou Anfu has achieved significant milestones in intellectual property, holding 14 independent rights including:

    • 2 Invention Patents
    • 5 Utility Model Patents
    • 4 Appearance Patents
    • 9 Software Copyrights

    Research and Development Commitment

    The company prioritizes independent research and development, investing heavily in product research and design annually. This dedication has led to the serial production of the AX200 chip series and the development of multiple industry-specific security solutions.

    Market Presence and Strategic Management

    Through leading technology, strategic decision-making, and standardized management practices, Shenzhou Anfu has grown into a renowned enterprise in the field of security encryption. It now serves as an independent security chip and module supplier, as well as an intelligent security terminal provider, catering to sectors like security, banking, finance, e-government, and convenience services both domestically and internationally.


    Specification


    Operating SystemLinux 5.4
    RTOS
    ProcessorLinux:Cortex-A7 1.2 GHz
    RTOS:Cortex-A5 500MHz
    High performance 32-bit security CPU
    MemoryLinux:256MB Flash + 128MB RAM
    RTOS:8MB Flash + 16MB RAM
    Card ReadersMSR: ISO7810-7813, 3 tracks
    IC Card: ISO7816
    NFC Reader13.56MHz, ISO/IEC14443 TypeA&B,
    CameraRear camera:0.3 million pixels
    Display2.8" 320x240 TFT
    Resistive Touch Screen
    Wireless CommunicationLinux:Wi-Fi® (2.4G) (optional)| 4G(Cat-4) | 3G (WCDMA) | 2G(GPRS)
    RTOS:Wi-Fi® (2.4G)(optional) | 4G(Cat-1) | 2G(GPRS)
    Batteryemovable Lithium polymer
    battery, 3.7V/2500mAh | 3.7V/3200mAh (optional)
    PrinterHigh speed thermal printing, printing lifeis not less than 50km
    The specification is 58mm in width and 40mm in diameter
    Card Slots
    SIM / SAM
    SIM Card x 2 + PSAM X 1
    PositioningX
    KeypadNumeric x 10
    Function x 8
    Power x 1
    Audio1 Buzzer
    PortsLinux:1 Type-C USB OTG | USB 2.0
    RTOS:11 Type-C | USB 2.0
    Indicator lights4 Work indicator lights
    AdapterInput: AC 100-240V, 50/60Hz
    Output: 5V/1A
    Scanning charging baseX
    Weight340g
    Physical size177mm*81mm*56mm
    EnvironmentStorage temperature: -20°C to 60°C
    Operating temperature: -10°C to 50°C
    Humidity: ≤95%
    CertificationsEMV Contact L1/EMV Contact L2/EMV Contactless L1 / Visa payWave /Mastercard Paypass
    PCI PTS 6.x / TQM / CE
    Display2.8"(320 x 240)TFT, resistive touch screen
    WlFl(optional)802.11 a/b/g/n,2.4G
    Mobile communicationLinux:4G CAT4,WCDMA,GSM
    RTOS:4G CAT1,GSM
    South American Version
    FDD-LTE:B2/B3/B4/B5/B7/B8/B28-A/B28-B;
    TDD-LTE:B40
    GSM:B2/B3/B5/B8
    European Version
    FDD-LTE:B1/B3/B5/B7/B8/B20;
    TDD-LTE:B38/B40/B41
    GSM:B3/B8
    Contact lC cardComply with lS0 7816 and China financial
    integrated circuit (lC) card specification;
    The card holder can be used for more than300000 times
    Magnetic stripe cardSupport three track data reading;
    It supports two-way card swiping.
    The swipingspeed ranges from 10 cm /s to 100 cm /s.
    The service life of the magnetic stripe reader canreach more than 400000 times;
    It conforms to iso78ll and iso7812 standards
    RTCBuilt in RTC to save the clock; Buttonbattery life > 5 years

    Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75

    Real Case for Lower MOQ:

    Products NameMOQ(in the last 12month)
    POS Device5 Pieces

    The competitive advantage of product line:

    Shenzhou Anfu has obtained 14 independent intellectual property rights, including 2 invention patents, 5 utility model patents, 4 appearance new patents and 9 software copyrights. In terms of product research and development, the company has always adhered to the road of independent research and development. The company has invested a large amount of funds each year in product R&D and design, realized serialized mass production of AX200 chip products, and launched safety in multiple industries based on this solution.


    Certificate


    Portable Wireless NFC POS Handheld Parking Ticket POS Terminal Machine With Printer 1D/2D QR Scanner AF75


    FAQ


    1. Q: How can I get the touch pos terminal sample to check quality?

    After price comfirmation, you can order pos samples to check quality.

    Contact:whatsapp +86 18011965815


    2. Q. How can we promise you the quality ?
    Each of our products will be FULL tested and Inspected before it shipped,


    3. Q: How can I become your agent?

    A: Welcome to become our agent. Please contact with our sales for application form for our evaluation.


    4. Q: Who will pay the postage of the returns?

    A: Within the warranty, returning postage happening in China will be free of charge. (Returns happening outside China mainland excluded.)


    5. Q:What is your warranty?

    We offer 12-months warranty, lifelong maintenance service. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
